Aircraft

• Takeoff Weight

• ‌< 249 g

  ^{‌Standard aircraft weight (including the Intelligent Flight Battery and a microSD card). Actual product weight may vary due to differences in batch materials and other factors. Training or examination is not required for flying this product in most countries and regions. Always check local laws and regulations before use. Always check and strictly abide by local laws and regulations before flying.}

• Dimensions

• Folded: 136×62×165 mm (L×W×H)
  Unfolded: 233×280×79 mm (L×W×H)

• Max Ascent Speed

• 5 m/s (Sport mode)
  5 m/s (Normal mode)
  2 m/s (Cine mode)

• Max Descent Speed

• 5 m/s (Sport mode)
  5 m/s (Normal mode)
  1.5 m/s (Cine mode)

• Max Horizontal Speed

• At sea level, in windless conditions:
  12 m/s* (Sport mode)
  12 m/s (tracking status)
  At sea level, with 4 m/s tailwind, while flying in the same direction as the wind:
  16 m/s* (Sport mode)
  12 m/s (tracking status)

  ^{* Measured in a wind tunnel test environment with the aircraft taking off from an altitude of 0 m and ascending vertically by 1.5 m in Sport mode. Data is for reference only. Always pay attention to reminders on the camera view during your flight.}

• Max Takeoff Altitude

• 3000 m

  ^{In a windless environment, a fully charged aircraft can take off from an altitude of 3000 m, ascend vertically by 500 m, and fly in Sport mode until the battery level drops to 20%. Data is for reference only. Always pay attention to reminders on the camera view during your flight.}

• Max Flight Time

• 31 minutes

  ^{Measured when flying forward at a constant speed of 6 m/s in a windless environment 20 m above sea level, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.}

• Max Hovering Time

• 28 minutes

  ^{Measured when hovering in a windless environment 20 m above sea level, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.}

• Max Flight Distance

• 14 km

  ^{Measured when flying forward at a constant speed of 9 m/s in a windless environment 20 m above sea level, in photo mode, and from 100% battery level until 0%. Actual experience may vary depending on the environment, usage, and firmware version.}

• Max Wind Speed Resistance

• 10.7 m/s (Level 5)

• Operating Temperature

• -10° to 40° C (14° to 104° F)

• Global Navigation Satellite System

• GPS + Galileo + BeiDou

• Hovering Accuracy Range

• Vertical:
  ±0.1 m (with vision positioning)
  ±0.5 m (with satellite positioning)

  Horizontal:
  ±0.3 m (with vision positioning)
  ±1.5 m (with satellite positioning)

• Internal Storage

• 2 GB

• Class

• C0 (EU)

Camera

• Image Sensor

• 1/1.3-inch image sensor

• Lens

• FOV: 82.1°
  Format Equivalent: 24 mm
  Aperture: f/1.7
  Focus: 1 m to ∞

• ISO Range

• Video
  Normal/Slow Motion:
  100-6400 (Normal)
  100-1600 (D-Log M)
  12MP Photo: 100-6400
  48MP Photo: 100-3200

• Shutter Speed

• 12MP Photo: 1/16000-2 s (2.5-8 s for simulated long exposure)
  48MP Photo: 1/8000-2 s

• Max Image Size

• 48MP Photo
  8064×6048

• Still Photography Modes

• Single Shot: 12 MP and 48 MP
  Burst Shooting:
  12 MP, 3/5/7 frames Automatic Exposure Bracketing (AEB):
  12 MP, 3/5/7 frames at 2/3 EV step
  Timed:
  12 MP, 2/3/5/7/10/15/20/30/60 s

• Photo Format

• JPEG
  DNG/RAW

• Video Resolution

• 4K: 3840×2160@24/25/30/48/50/60/100fps
  FHD: 1920×1080@24/25/30/48/50/60/100fps
  2.7K Vertical Shooting: 1512×2688@24/25/30fps
  FHD Vertical Shooting: 1080×1920@24/25/30fps

• Video Format

• MP4

• Max Video Bitrate

• 150Mbps

• Supported File System

• exFAT

• Color Mode

• Normal
  D-Log M

• Digital Zoom

• 4K: 3x
  FHD: 4x
  2.7K Vertical Shooting: 3x
  FHD Vertical Shooting: 4x
  12 MP Photo: 3x

Gimbal

• Stabilization

• 3-axis mechanical gimbal (tilt, roll, pan)

• Mechanical Range

• Tilt Axis: -130° to +63°
  Roll Axis: -47° to +47°
  Pan: -30° to +30°

• Controllable Range

• Tilt Axis: -90° to +35°

• Max Control Speed (tilt)

• 100°/s

• Angular Vibration Range

• ±0.01°

Sensing

• Sensing Type

• Downward: one visual sensor and an infrared sensor, Forward: 3D Infrared Sensing System

• Forward

• 3D Infrared Sensing System
  Measurement Range: 0.3-8 m (reflectivity > 10%)
  FOV: Horizontal 60°, Vertical 60°

• Downward

• Measurement Range: 0.3-8 m (reflectivity > 10%)
  Precise Hovering Range: 0.5-10 m
  FOV: Horizontal 60°, Vertical 60°

• Operating Environment

• Downward:
  Surfaces with discernible patterns, diffuse reflectivity > 20% (such as cement pavement), and adequate lighting (lux > 15)

Video Transmission

• Video Transmission System

• O4

• Live View Quality

• Remote Controller:
  Up to 1080p/60fps

• Operating Frequency

• 2.4000-2.4835 GHz
  5.170-5.250 GHz
  5.725-5.850 GHz

  ^{Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.}

• Transmitter Power (EIRP)

• 2.4 GHz:
  <30 dBm (FCC)
  <20 dBm (CE/SRRC/MIC)

  5.1 GHz:
  <23 dBm (CE)

  5.8 GHz:
  <33 dBm (FCC)
  <14 dBm (CE)
  <30 dBm (SRRC)

• Max Transmission Distance (unobstructed, free of interference)

• FCC: 13 km
  CE: 8 km
  SRRC: 8 km
  MIC: 8 km

  ^{Measured in an open, outdoor environment without interference or obstructions and represents the farthest communication range under each standard. The actual max transmission distance during flight is limited by the drone’s max flight distance. Always pay attention to RTH reminders on the camera view during your flight.}

• Max Transmission Distance (unobstructed, with interference)

• Strong Interference (urban landscape): Approx. 1-2.5 km
  Medium Interference (suburban landscape): Approx. 2.5-7 km
  Low Interference (suburb/seaside): Approx. 7-13 km

  ^{Measured under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual transmission distance.}

• Max Transmission Distance (obstructed, with interference)

• Low Interference and Obstructed by Buildings: Approx. 0-0.5 km
  Low Interference and Obstructed by Trees: Approx. 0.5-2 km

  ^{Measured under FCC standard in obstructed environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance.}

• Max Download Speed

• O4:
  DJI RC-N3 Remote Controller: 10 MB/s
  DJI RC: 10 MB/s
  Wi-Fi 5: 30 MB/s

  ^{Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz. Download speeds may vary depending on the actual conditions.}

• Lowest Latency

• Approx. 120 ms

  ^{Depending on the actual environment and mobile device.}

• Antenna

• 4 antennas (2.4 GHz: 1T2R; 5.2/5.8 GHz: 2T2R)

Wi-Fi

• Protocol

• 802.11a/b/g/n/ac

• Operating Frequency

• 2.4000 GHz-2.4835 GHz
  5.7250 GHz-5.850 GHz

  ^{Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.}

• Transmitter Power (EIRP)

• 2.4 GHz：
  <20 dBm（FCC/CE/SRRC/MIC）

  5.8 GHz：
  <20 dBm（FCC/SRRC）
  <14 dBm （CE）

• Effective Operating Range

• 50 m

  ^{Measured in an open environment free of interference. Actual transmission distance may vary by the operating environment.}

Bluetooth

• Protocol

• Bluetooth 5.0

• Operating Frequency

• 2.4000-2.4835 GHz

  ^{Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.}

• Transmitter Power (EIRP)

• ＜10 dBm

Battery

• Capacity

• 3110 mAh

• Weight

• Approx. 83.5 g

• Nominal Voltage

• 7.16 V

• Battery Type

• Li-ion

• Chemical System

• LiNiMnCoO2

• Energy

• 22.3 Wh

• Charging Temperature

• 5° to 40° C (41° to 104° F)

• Charging Time

• When Charging via Aircraft (30W max charging power):
  From 0% to 100%: Approx. 70 minutes*

  When Using the Battery Charging Hub for Charging One Battery (48W max charging power):
  From 0% to 100%: Approx. 45 minutes**

  When Using the Battery Charging Hub for Parallel Charging Two Batteries (65W max charging power):
  Two batteries from 0% to 100%: Approx. 70 minutes***

  ^{* Using the DJI 30W USB-C Charger or a charger that supports the PD protocol with a power output higher than 30 W.
  ** Using the DJI 65W USB-C Charger or a charger that supports the PD protocol with a power output higher than 48 W.
  *** Using the DJI 65W USB-C Charger or a charger that supports the PD protocol with a power output higher than 65 W.}

Battery Charging Hub

• Input

• 5 V, 4.3 A
  9 V, 4.3 A
  12 V, 4.3 A
  15 V, 4.3 A

• Output (power accumulation)

• Max 45 W

• Output (charging)

• 15 V, 2 A
  12 V, 2 A
  9 V, 3 A
  5 V, 3 A

• Rated Power

• 65 W

• Charging Type

• Supports Parallel Charging of Two Batteries

  ^{Parallel charging requires the DJI 65W Portable Charger or a charger with at least 65W output, 4.3A current at 15V, and PD protocol support, along with a charging cable rated for at least 5A and also supporting PD protocol. Otherwise, batteries will be charged individually.}

• Compatibility

• DJI Flip Intelligent Flight Battery

Charger

• Recommended Charger

• DJI 65W Portable Charger*
  USB Power Delivery chargers

  <sup>* When you charge the battery mounted to the aircraft, the maximum charging power supported is 30 W.
  * When you charge the battery inserted into the Parallel Charging Hub, the maximum charging power supported is 65 W.</sup>

Storage

• Recommended microSD Cards

• Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXC
  Kingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXC
  Kingston CANVAS Go! Plus 256GB U3 A2 V30 microSDXC
  Kingston CANVAS Go! Plus 512GB U3 A2 V30 microSDXC
  Lexar Professional 1066x 64GB U3 A2 V30 microSDXC
  Lexar Professional 1066x 128GB U3 A2 V30 microSDXC
  Lexar Professional 1066x 256GB U3 A2 V30 microSDXC
  Lexar Professional 1066x 512GB U3 A2 V30 microSDXC

DJI RC-N3 Remote Controller

• Max Operating Time

• Without Charging Any Mobile Device: 3.5 hours
  When Charging a Mobile Device: 1.5 hours

• Operating Temperature

• -10° to 40° C (14° to 104° F)

• Max Supported Mobile Device Size

• 180×86×10 mm (L×W×H)

App

• Mobile Device App

• DJI Fly

• Required Operating System

• iOS 13.0 or later
  Android 7.0 or later
